- The maximum resolution of up to 3MP
- The use of advanced video compression technology , high compression ratio , and flexible processing
- Progressive scan CMOS, capture moving images without jagged
- Support for 3D digital noise reduction function
- Efficient infrared light , long life, irradiation distance of up to 45 m
- ICR filter automatic switch for true day and night surveillance
- Support PoE
- Support dual-stream , Support mobile phone monitoring
- Comply with IP66-rated dust and waterproof design , high reliability
- Support BLC , WDR , automatic electronic shutter function , adapt to different control environment
- Functional: a key recovery , heart , mirror, watermarks , etc.
|
Camera
|
Image Sensor:
|
1/3" Progressive Scan CMOS
|
|
Minimum Illumination:
|
0.19 lux /F2.0, AGC ON
|
|
0 lux with IR
|
|
Shutter Time:
|
1/30s ~ 1/100,000s
|
|
Lens:
|
Standard/Default 6mm/F2.0 (6mm, 8mm,12mm optional)
|
|
Angle of view: 48° with 6mm lens
|
|
Lens Mount:
|
M12
|
|
Day& Night:
|
Electronic (-I: IR cut filter with auto switch)
|
|
Digital Noise Reduction:
|
3D DNR
|
|
Wide Dynamic Range:
|
Digital WDR
|
|
Compression Standard
|
Video Compression:
|
H.264/M-JPEG
|
|
H.264 Compression Profile:
|
Main profile
|
|
Bit Rate:
|
32 Kbps~16Mbps
|
|
|
Max Image Resolution:
|
2048×1536
|
|
Frame Rate:
|
60Hz: 15fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 x 720)
|
|
Image Settings:
|
Saturation, brightness, contrast adjustable through client software or web browser
|
|
BLC:
|
Yes, zone configurable
|
|
Network
|
Network Storage:
|
NAS
|
|
Alarm Trigger:
|
Motion detection, tampering alarm, network disconnect, IP address conflict, storage full, storage error
|
|
Protocols:
|
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, ICMP,IGMP,SNMP, FTP, 802.1X, QoS, HTTPS
|
|
System Compatibility:
|
ONVIF, PSIA, CGI
|
|
General Functionalities (Security):
|
User Authentication, reset button, flickerless, dual stream, heartbeat, mirror, watermark
|
|
Interface
|
Communication Interface:
|
1 RJ45 10 M/100 M Ethernet port
|
|
General
|
Power Supply:
|
12 V DC ± 10%; PoE (802.3af)
|
|
Power Consumption:
|
Max. 5W (7W with ICR on)
|
|
Working Temperature (Operating Conditions):
|
-30°C ~ 60°C (-22°F ~ 140°F) humidity 95% or less (non-condensing)
|
|
Impact Protection:
|
IEC60068-275Eh, 50J; EN50102, exceeding IK10
|
|
IR Range:
|
Up to 45m
|
|
Dimensions:
|
Please check the size as below
|
|
Weight:
|
700g
|
|
Weather Proof:
|
IP66
|
|
|
|
|
| Payment Terms︰ | TT/Paypal/Western Union |
| Optional Version&Features︰ | The maximum resolution of up to 3MP
The use of advanced video compression technology , high compression ratio , and flexible processing
Progressive scan CMOS, capture moving images without jagged
Support for 3D digital noise reduction function
Efficient infrared light , long life, irradiation distance of up to 45 m
ICR filter automatic switch for true day and night surveillance
Support PoE
Support dual-stream , Support mobile phone monitoring
Comply with IP66-rated dust and waterproof design , high reliability
Support BLC , WDR , automatic electronic shutter function , adapt to different control environment
Functional: a key recovery , heart , mirror, watermarks , etc. |
| Product Series︰ | HIKVISION 3.0MP HD IP Cameras 2 Series |
|
|
